With the production technologies we have developed, we can produce barrels at the highest quality standards. Nitrided or bimetallic barrels we produce provide high performance and abrasion protection.
We can manufacture barrels in all desired designs such as shank, grooved, and bushing with a different cooling system according to customer requirements and material samples.
Production capability up to diameter 18-300 mm length 5000 mm.
Corrosion resistant
Abrasion resistant
High surface roughness
| Material No | AISI | DIN | Abrasion | Corrosion | Surface Hardness | Depth |
|---|---|---|---|---|---|---|
| 1.8519 | - | 31CrMoV9 | *** | *** | 800-850 HV | 0.5-0.6 mm |
| 1.8550 | - | 34CrAlNi7 | *** | *** | 900-1000 HV | 0.5-0.6 mm |
| 1.7225 | 4140 | 42CrMo4 | ** | *** | 600-700 HV | 0.5-0.6 mm |
| Material No | Abrasion | Corrosion | Surface Hardness | Thickness |
|---|---|---|---|---|
| BM21 | **** | *** | 65-69 HV | 2.5-3.5 mm |
| Material No | Abrasion | Corrosion | Surface Hardness | Thickness |
|---|---|---|---|---|
| BM15 | **** | **** | 65-69 HV | 2.5-3.5 mm |
